Material and Plating | ||
Components | Material | Plating |
Center conductor | bronze | Au |
Body | Brass | CuSnZn |
Insulator | PTFE | / |
Gasket | Rubber | / |
Electrical data | |
Characteristic Impedance | 50 Ohm |
Frenquency Range | DC-3 GHz |
VSWR | ≤1.2 |
Dielectric Withstanding Voltage | ≥2500V(rms) |
Dielectric Resistance | 5000 MΩ |
Center Contact Resistance | ≤1.0 mΩ |
Outer Contact Resistance | ≤1.5 mΩ |
Durability | Mating Cycles≥500 |
