| Material and Plating | ||
| Components | Material | Plating |
| Center conductor | bronze | Ag |
| Body | Brass | CuSnZn |
| Insulator | PTFE | / |
| Gasket | Rubber | / |
| Electrical data | |
| Characteristic Impedance | 50 Ohm |
| Frenquency Range | DC-3 GHz |
| VSWR | ≤1.15 |
| Dielectric Withstanding Voltage | ≥2500V（rms） |
| Dielectric Resistance | 5000 MΩ |
| Center Contact Resistance | ≤1.0 mΩ |
| Outer Contact Resistance | ≤1.5 mΩ |
| PIM | ≤-155 dBc |
| Durability | Mating Cycles≥500 |
