Material and Plating | ||
Components | Material | Plating |
Center conductor | bronze | Ag |
Body | Brass | CuSnZn |
Insulator | PTFE | / |
Gasket | Rubber | / |
Electrical data | |
Characteristic Impedance | 50 Ohm |
Frenquency Range | DC-18 GHz |
VSWR | ≤1.15 |
PIM@2*43 dBm | 160 dBc |
Durability | Mating Cycles≥100 |
