| Material and Plating | ||
| Components | Material | Plating |
| Center conductor | bronze | Au |
| Body | Brass | Ni |
| Insulator | PTFE | / |
| Gasket | Rubber | / |
| Electrical data | |
| Characteristic Impedance | 50 Ohm |
| Frenquency Range | DC-4 GHz |
| VSWR | ≤1.22 |
| Dielectric Withstanding Voltage | ≥4000V（rms） |
| Dielectric Resistance | 10000 MΩ |
| Center Contact Resistance | ≤0.4 mΩ |
| Outer Contact Resistance | ≤2.5 mΩ |
| Durability | Mating Cycles≥500 |
